A More Practical Guide to JUnit 5 Parameterized Tests


In this tutorial we will learn how to write JUnit 5 parameterized tests. The tutorial is structured so that it also answers most asked questions about parameterized tests.

This article is part of the JUnit 5 Tutorial.

Table of Contents

Overview

Parameterized tests make it possible to run the same test multiple times with different arguments. This way, we can quickly verify various conditions without writing a test for each case.

We can write JUnit 5 parameterized tests just like regular JUnit 5 tests but have to use the @ParameterizedTest annotation instead. We will also have to declare an argument source for the test. We declare these argument sources with different argument source annotations.

Do you only need one argument?

The simplest argument source is the @ValueSource argument source. It lets us specify an array of literals of primitive types (either short, byte, int, long, float, double, char, boolean, String, or Class).

Here is an example of using different strings as the test argument.

@ParameterizedTest
@ValueSource(strings = { "level", "madam", "saippuakivikauppias" })
void palindromeReadsSameBackward(String string) {
    assertTrue(StringUtils.isPalindrome(string));
}

By the way, saippuakivikauppias means soapstone vendor in Finnish.

When we run the test, we can see from the output that the test method executed three times with different values of the string.

palindromeReadsSameBackward(String)
├─ [1] level
├─ [2] madam
└─ [3] saippuakivikauppias

Here is another example, where we provide ints to our parameterized test.

@ParameterizedTest
@ValueSource(ints = { 3, 6, 15})
void divisibleByThree(int number) {
    assertEquals(0, number % 3);
}

Another source of a single argument is the @EnumSource annotation. The annotation takes an enum type as an argument and provides the test with the enum constants.

For example:

enum Protocol {
    HTTP_1_0, HTTP_1_1, HTTP_2
}
@ParameterizedTest
@EnumSource(Protocol.class)
void postRequestWithDifferentProtocols(Protocol protocol) {
    webServer.postRequest(protocol);
}

If we run the test, we can see that the test has been executed once per every value of the Protocol enumeration.

What about null values?

The @ValueSource annotation doesn’t accept null values.

There is one special annotation called @NullSource that will provide a null argument for the test. Another special annotation is @EmptySource, which provides an empty value for either a String, List, Set, Map, or an array.

In this example, we are passing the values of null, an empty string, and a blank string to the test method.

@ParameterizedTest
@NullSource
@EmptySource
@ValueSource(strings = { " " })
void nullEmptyAndBlankStrings(String text) {
    assertTrue(text == null || text.trim().isEmpty());
}

It is also possible to use @NullAndEmptySource which combines the two.

Do you need multiple arguments?

The @ValueSource and @EnumSource annotations only work when our test method takes one argument. However, we often need more than that.

@MethodSource allows us to refer to a factory method that returns the arguments. Such methods must return a Stream, Iterable, Iterator, or an array of arguments.

Let’s assume that we have a DateUtils class that gets the name of the month for a number. We need to pass multiple parameters in our parameterized test, so we can use a Stream of Arguments in our factory method.

@ParameterizedTest
@MethodSource("numberToMonth")
void monthNames(int month, String name) {
    assertEquals(name, DateUtils.getMonthName(month));
}

private static Stream<Arguments> numberToMonth() {
    return Stream.of(
            arguments(1, "January"),
            arguments(2, "February"),
            arguments(12, "December")
    );
}

When we refer the factory method in @MethodSource, it will then provide the test with different values of month and name parameters.

If we don’t provide a method name to the @MethodSource annotation, JUnit 5 will try to find a method with the same name instead.

@ParameterizedTest
@MethodSource
void monthNames(int month, String name) {
    assertEquals(name, DateUtils.getMonthName(month));
}

private static Stream<Arguments> monthNames() {
    return Stream.of(
            arguments(1, "January"),
            arguments(2, "February"),
            arguments(12, "December")
    );
}

Do you want to share your argument providers between tests?

It is possible to refer to a method in another class in @MethodSource. We have to use the fully qualified name of the method name to do so.

package com.arhohuttunen;

import java.util.stream.Stream;

public class StringsProvider {
    private static Stream<String> palindromes() {
        return Stream.of("level", "madam", "saippuakivikauppias");
    }
}

The fully qualified name is a combination of the package name, class name, and the method name.

@ParameterizedTest
@MethodSource("com.arhohuttunen.StringsProvider#palindromes")
void externalPalindromeMethodSource(String string) {
    assertTrue(StringUtils.isPalindrome(string));
}

Another option for sharing is to write a custom class that implements the ArgumentsProvider interface.

public class PalindromesProvider implements ArgumentsProvider {
    @Override
    public Stream<? extends Arguments> provideArguments(ExtensionContext context) {
        return Stream.of("level", "madam", "saippuakivikauppias").map(Arguments::of);
    }
}

This can be then specified in the test with the @ArgumentsSource annotation.

@ParameterizedTest
@ArgumentsSource(PalindromesProvider.class)
void externalPalindromeMethodSource(String string) {
    assertTrue(StringUtils.isPalindrome(string));
}

Do you have a lot of data?

The @CsvSource annotation allows us to use a list of comma-separated string values. Using the annotation makes it possible to provide multiple parameters to the test method in quite a compact way.

@CsvSource({
        "Write a blog post, IN_PROGRESS, 2020-12-20",
        "Wash the car, OPENED, 2020-12-15"
})
void readTasks(String title, Status status, LocalDate date) {
    System.out.printf("%s, %s, %s", title, status, date);
}

If we write a lot of test data in the test code, the test quickly becomes unreadable. One solution is to provide the data in an external CSV file using the @CsvFileSource annotation.

Using the previous example, we start by creating a comma-separated list of parameters in tasks.csv file that we will put in src/test/resources. Each line from the file works as a list of parameters.

Write a blog post, IN_PROGRESS, 2020-12-20
Wash the car, OPENED, 2020-12-15

Next, we use the @CsvFileSource annotation to provide the test method with the data.

@ParameterizedTest
@CsvFileSource(resources = "/tasks.csv")
void readTasks(String title, Status status, LocalDate date) {
    System.out.printf("%s, %s, %s", title, status, date);
}

How to provide empty CSV arguments?

If @CsvSource has an empty value, JUnit 5 will always treat it as null.

@ParameterizedTest
@CsvSource(", IN_PROGRESS, 2020-12-20")
void nullArgument(String title, Status status, LocalDate date) {
    assertNull(title);
}

The string needs to be quoted with single quotes, so that it becomes an empty string.

@ParameterizedTest
@CsvSource("'', IN_PROGRESS, 2020-12-20")
void emptyArgument(String title, Status status, LocalDate date) {
    assertTrue(title.isEmpty());
}

If we would like to replace some specific string with null values, we can use the nullValues argument of @CsvSource.

@ParameterizedTest
@CsvSource(value = "NULL, IN_PROGRESS, 2020-12-20", nullValues = "NULL")
void customNullArgument(String title, Status status, LocalDate date) {
    assertNull(title);
}

How to convert strings into different types?

To better support use cases like @CsvSource, JUnit 5 does automatic argument conversion for primitive types, enums, and the date and time types from the java.time package. The conversion depends on the type of each method parameter.

This means, for example, that it automatically converts the following date strings to LocalDate instances.

@ParameterizedTest
@ValueSource(strings = { "2018-01-01", "2018-01-31" })
void convertStringToLocalDate(LocalDate localDate) {
    assertEquals(Month.JANUARY, localDate.getMonth());
}

JUnit 5 parameterized tests support many more types by default. Instead of going through all of them here, we can check the JUnit 5 implicit conversion documentation for a list of target types.

If JUnit 5 is not able to convert the argument, it will try to call either of the two in the target type:

  1. A constructor with a single String argument
  2. A static method accepting a single String argument, which returns an instance of the target type

In the following example, JUnit 5 will call the constructor of Person to do the type conversion from String.

public class Person {
    private String name;

    public Person(String name) {
        this.name = name;
    }
}
@ParameterizedTest
@CsvSource("John Doe")
void fallbackStringConversion(Person person) {
    assertEquals("John Doe", person.getName());
}

Consequently, the implementation of that Person class in the next example would work as well.

public class Person {
    private final String name;

    public static fromName(String name) {
        return new Person(name);
    }
}

How to convert your custom types?

If we need to write a custom argument converter, we need to implement the ArgumentConverter interface. We can then annotate any parameters needing custom conversion with the @ConvertWith annotation.

For example’s sake, let’s write an argument converter that converts hex values into decimal values. Instead of implementing ArgumentConverter, we can also extend TypedArgumentConverter if the converter only handles one type.

class HexConverter extends TypedArgumentConverter<String, Integer> {
    protected HexConverter() {
        super(String.class, Integer.class);
    }

    @Override
    public Integer convert(String source) throws ArgumentConversionException {
        try {
            return Integer.parseInt(source, 16);
        } catch (NumberFormatException e) {
            throw new ArgumentConversionException("Cannot convert hex value", e);
        }
    }
}

Next, in our test, we need to annotate the parameter that needs custom conversion with @ConvertWith.

@ParameterizedTest
@CsvSource({
        "15, F",
        "16, 10",
        "233, E9"
})
void convertWithCustomHexConverter(int decimal, @ConvertWith(HexConverter.class) int hex) {
    assertEquals(decimal, hex);
}

To make the test itself a little less technical and more readable, we can further create a meta-annotation that wraps the conversion.

@Target({ ElementType.ANNOTATION_TYPE, ElementType.PARAMETER })
@Retention(RetentionPolicy.RUNTIME)
@ConvertWith(HexConverter.class)
public @interface HexValue {
}

Now we can use our new composed annotation to make the test more readable.

@ParameterizedTest
@CsvSource({
        "15, F",
        "16, 10",
        "233, E9"
})
void convertWithCustomHexConverter(int decimal, @HexValue int hex) {
    assertEquals(decimal, hex);
}

How to convert multiple arguments into a single object?

By default, arguments provided to a parameterized test correspond to a single method parameter. It is possible to aggregate these arguments into a single test method argument using a ArgumentsAccessor.

To create a more readable and reusable arguments aggregator, we can write our own.

public class TaskAggregator implements ArgumentsAggregator {
    @Override
    public Object aggregateArguments(
            ArgumentsAccessor accessor,
            ParameterContext context
    ) throws ArgumentsAggregationException {

        return new Task(
                accessor.getString(0),
                accessor.get(1, Status.class),
                accessor.get(2, LocalDate.class)
        );
    }
}
@ParameterizedTest
@CsvSource({
        "Write a blog post, IN_PROGRESS, 2020-12-20",
        "Wash the car, OPENED, 2020-12-15"
})
void aggregateArgumentsWithAggregator(@AggregateWith(TaskAggregator.class) Task task) {
    System.out.println(task);
}

Just like with the custom argument converter, we can also create a shorthand annotation for the aggregator.

@Retention(RetentionPolicy.RUNTIME)
@Target(ElementType.PARAMETER)
@AggregateWith(TaskAggregator.class)
public @interface CsvToTask {
}
@ParameterizedTest
@CsvSource({
        "Write a blog post, IN_PROGRESS, 2020-12-20",
        "Wash the car, OPENED, 2020-12-15"
})
void aggregateArgumentsWithAnnotation(@CsvToTask Task task) {
    System.out.println(task);
}

Now we can use the aggregator annotation anywhere we want to.

How to customize display names?

By default, JUnit 5 parameterized tests' display names include the invocation index and String representation of all the parameters. However, we can customize the display name via the name attribute of the @ParameterizedTest annotation.

Let’s take a look at the previous month names example again.

@ParameterizedTest(name = "{index} => number={0}, month={1}")
@MethodSource
void monthNames(int month, String name) {
    assertEquals(name, DateUtils.getMonthName(month));
}

private static Stream<Arguments> monthNames() {
    return Stream.of(
            arguments(1, "January"),
            arguments(2, "February"),
            arguments(12, "December")
    );
}

The name attribute holds placeholders for {index} that is the index of the current test invocation and {0}, {1}, … that is the actual parameter value.

Now when we run the test we get output similar to this:

 monthNames(int, String)
├─ 1 => number=1, month=January
├─ 2 => number=2, month=February
└─ 3 => number=12, month=December

Summary

JUnit 5 parameterized tests allow us to remove duplication from test code. They make it possible to execute the same test several times using different inputs.

  • Using @ValueSource is enough in most cases when we have just one argument, but we can also use @EnumSource, @NullSource and @EmptySource
  • If there are multiple arguments @MethodSource is the right choice in most cases, and we can reuse providers with @ArgumentsSource
  • For data-driven tests we can use @CsvFileSource
  • You can write our custom argument conversions with ArgumentConverter
  • To customize arguments aggregation we can use ArgumentsAggregator

The example code for this guide can be found in GitHub.
